Structural Specifications
| ● |
Surface : Diecast aluminium |
| ● |
Glass: Hardened safety tempered glass (wear-resistant) |
| ● |
Static load resistance of flanged housing: 2000 kg |
| ● |
Luminaire body material: CNC-machined 6061 aluminum |
| ● |
Mounting part material: PVC plastic (for diameter ＞136mm); CNC-machined 6061 aluminum (for diameter ＜136mm) |
| ● |
Surface treatment: Hard anodizing is applied to both the luminaire body and pre-embedded mounting box, featuring high corrosion resistance (suitable for soils with different salinity levels), a salt spray test duration of ＞ 1000h, high wear resistance, and easy cleaning |
| ● |
Surface screws: 304 stainless steel screws (for diameter ＞136mm); screwless design (for diameter ＜136mm); waterproof screws: nickel-plated copper |
Protection & Performance Ratings
| ● |
IP rating: IP65 |
| ● |
IK rating: IK05 |
| ● |
LED chip brands: Cree, Bridgelux, Luminus (selected based on the optical and chip requirements of different luminaire models) |
| ● |
Standard color temperatures: 2700K, 3000K, 4000K, 6000K, RGB, RGBW |
| ● |
Color Rendering Index (CRI): ≥90 |
| ● |
MacAdam Step: ≤3LED |
| ● |
Lifetime: 100,000h - L80 - B10 (at Ta = 40°C; i.e., 80% luminous flux retention with a 10% failure probability at an ambient temperature of 40°C) |
| ● |
Operating ambient temperature range: -20°C ~ 50°C |
Electrical & Control Specifications
| ● |
Operating voltage options: DC24V |
| ● |
Power cable specifications: |
| ● |
AC220-240V: 3×1mm² |
| ● |
DC24V (＜50W): 2×0.75mm² |
| ● |
DC24V (＞50W): 2×1mm² |
| ● |
DC24V (1W): 2×0.5mm² |
| ● |
Luminaire control options: ON/OFF, Dimmable; Built-in or external DALI, 0–10V, or DMX512 driver |
| ● |
Output power cable length: The luminaire is equipped with a 300mm or 500mm long output power cable; specifications must be specified when placing an order cable; specifications must be specified when placing an order |
Mounting Accessories
| ● |
Pre-embedded mounting boxes suitable for wall and ground installation |
