Structural Specifications
| ● |
Surface :6061 Aluminium |
| ● |
Glass: Hardened tempered glass |
| ● |
Lamp Head Weight: 4KG |
| ● |
Luminaire body material: Die-cast aluminum; CNC-machined 6061 aluminum |
| ● |
Surface treatment: Both the main body and the embedded installation box are treated electrostatic spraying, a salt spray test duration of ＞ 1000h, high wear resistance, and easy cleaning |
| ● |
Surface screws: 304 stainless steel screws; screwless design ; waterproof screws: nickel-plated copper |
Protection & Performance Ratings
| ● |
IP rating: IP65 |
| ● |
IK rating: IK07 |
| ● |
LED chip brands: Cree, Bridgelux, Luminus (selected based on the optical and chip requirements of different luminaire models) |
| ● |
Standard color temperatures: Single white light |
| ● |
Color Rendering Index (CRI): ≥90 |
| ● |
MacAdam Step: ≤3 |
| ● |
Lifetime: 100,000h - L80 - B10 (at Ta = 40°C; i.e., 80% luminous flux retention with a 10% failure probability at an ambient temperature of 40°C) |
| ● |
Operating ambient temperature range: -20°C ~ 50°C |
Electrical & Control Specifications
| ● |
Operating voltage options: DC24V(needs to be purchased separately)/AC220V |
| ● |
Power cable specifications: |
| ● |
AC220-240V: 3×1mm² |
| ● |
DC24V (＜50W): 2×0.75mm² |
| ● |
DC24V (＞50W): 2×1mm² |
| ● |
DC24V (1W): 2×0.5mm² |
| ● |
Luminaire control options:Built-in constant current, external DC24V(needs to be purchased separately) |
| ● |
Output power cable length: The luminaire is equipped with a 300mm or 500mm long output power cable; specifications must be specified when placing an order cable; specifications must be specified when placing an order |
Mounting Accessories
| ● |
Pre-embedded mounting boxes suitable for wall and ground installation |
